Current Measurement

Attention!

First switch off the power supply to the measuring circuit and/or to the load, and discharge any capacitors which might be present.

A? Select function A with the function selector switch for currents > 400 mA, or function mA for currents < 400mA.

B? Each time the key is pressed, alternate switching takes place between AC and DC, and change over is acknowledge by sound signal. The symbols – -DC and ~ AC indicate the selected current type in the LCD display.
